Engine and Transmission

Engine Capacity	177.4 cc
Engine Type	4- Stroke, 1- Cylinder, Air- Cooled, SI Engine
Max Power	17.13 PS @ 9000 rpm
Max Torque	15.5 Nm @ 7000 rpm
Transmission	5 Speed Manual
Drive Type	Chain Drive
Clutch	Wet Multiplate
Bore	62 mm
Stroke	58 mm
Compression Ratio	10.0 : 1
Emission Standard	BS6 - 2
Fuel Type	Petrol
Starting Mechanis	Self Start Only

Features

Fully Digital Console	Digital
Speedometer	Digital
Odometer	Digital
Tripmeter	Digital
Tachometer	Digital
Seat Type	Single
Graphics	Yes

Features and Safety

Pass Light	Yes
Shift Light	No
Traction Control	No
Clock	Yes
Footrest	Yes
Kill Switch	Yes
Saree Guard	Yes
Display	Yes
Service Reminder Indicator	Yes
Gear Position Indicator	Yes
Malfunction Indicator	Yes

Mileage and Performance

Mileage (ARAI)	45 kmpl
Acceleration	0 - 60 kmph, 4.5 S
Acceleration	0 - 100 kmph, 13 s

Chassis and Suspension

Frame Type	Double Cradle Synchro STIFF
Front Suspension	Telescopic Fork
Back Suspension	Gas - Charged Mono Shock
Front Suspension Preload Adjustable	No
Back Suspension Preload Adjustable	Yes

Dimensions and Capacity

Kerb Weight	140 kg
Fuel Tank Capacity	12 L
Reserve Fuel Capacity	2 L
Seat Height	790 mm
Ground Clearance	180 mm
Length	2085 mm
Width	730 mm
Height	1105 mm
Wheelbase	1326 mm

Electricals

Headlight Type	LED
Projector Headlight	No
Taillight	LED
DRLs (Daytime Running Lights)	Yes
Hazard Warning Lights	No
Turn Signal	Halogen Bulb
Low Fuel Indicator	Yes
Low Oil Indicator	Yes

Tyres and Brakes

Front Tyre Size	90/90 - 17
Back Tyre Size	120/70 - 17
Tyre Type	Tubeless
Wheel Type	Alloy
Front Brake Type and Size	Disc, 270 mm
Back Brake Type and Size	Disc, 200 mm
Braking System	Single Channel

Performance

Top Speed

113 kmph

Motor & Battery

Max Power	7.13 PS @ 9000 rpm
Battery Capacity	12V, 6Ah

Underpinnings

1st Service	500-750 Kms/30 Days
2nd Service	2500-3000 Kms/90 Days
3rd Service	5000-6000 Kms/180 Days
4th Service	8500-9000 Kms/11500-12000 Days

What's Include

Basic Warranty	5 Years
Basic Warranty	60000 km

App Features

Turn-by-Turn Navigation	Yes
Bluetooth Connectivity	Yes
Call/SMS/Alerts	Yes
