Engine and Transmission

Engine Capacity	109.7 cc
Engine Type	4- Stroke, 1- Cylinder, Air- Cooled Engine
Max Power	7.8 PS @ 7500 rpm
Max Torque	8.8 Nm @ 5500 rpm
Transmission	Automatic
Drive Type	Belt Drive
Bore	53.5 mm
Stroke	48.8 mm
Compression Ratio	10 : 1
Emission Standard	BS6 - 2
Fuel Type	Petrol
Starting Mechanism	King and Self Start

Features

Instrument Console	Analogue
Speedometer	Analogue
Odometer	Analogue
Tripmeter	Analogue
Seat Type	Single
Shutter Lock	Yes

Features and Safety

Pass Light	Yes
Footrest	Yes
Side Stand Engine Cut-off	Yes

Mileage and Performance

Mileage (ARAI)	48 kmpl
Acceleration	0 – 60 kmph, 11.1 s

Chassis and Suspension

Frame Type	Duplex Tubular Frame
Front Suspension	Telescopic Fork
Back Suspension	Double Rated Hydraulic Mono Shock
Front Suspension Preload Adjustable	No
Back Suspension Preload Adjustable	No

Dimensions and Capacity

Kerb Weight	103 kg
Fuel Tank Capacity	5 L
Seat Height	760 mm
Ground Clearance	150 mm
Length	1770 mm
Width	660 mm
Height	1139 mm
Wheelbase	1250 mm

Electricals

Headlight Type	Halogen
Taillight	LED
DRLs (Daytime Running Lights)	Yes
Turn Signal	Bulb
Low Fuel Indicator	Yes

Tyres and Brakes

Front Tyre Size	90/100-10
Back Tyre Size	90/90 - 10
Tyre Type	Tubeless
Wheel Type	Alloy
Front Brake Type and Size	Drum, 110 mm
Back Brake Type and Size	Drum, 130 mm
Braking System	Synchronized Braking System

Performance

Top Speed

80 kmph

Motor & Battery

Max Power	7.8 PS @ 7500 rpm
Battery Capacity	12V, 5Ah

Underpinnings

1st Service	500-750 Kms/60 Days
2nd Service	2500-3000 Kms/120 Days
3rd Service	5000-6000 Kms/240 Days
4th Service	8500-9000 Kms
Stand Alarm	Yes
High Beam Indicator	Yes
Hazard Warning Indicator	Yes
Malfunction Indicator	Yes

What's Include

Basic Warranty

5 Years
